Key Features
- Function Identification purpose
- Structure Tailored to specific requirements
- Data Transmission Mode Uses serial communication method
- Application Field Utilized in security, banking, identity management
- Transport Package Packaged in standard box for transport
- Specification Dimensions measure 94*60*10mm
Technical Specifications
| Support | EM4100, EM4200, TK4100, T5577, EM4305 |
| Operating System | Windows98, XP7, LIUNX, Android |
| Frequency | 125 Khz,13.56 mhz |
| Reading Distance | 0 in to 3.15in (0 mm to 80 mm) |
| Interface | USB (RS232 is optional) |
| Operating Humidity | -4 °F to 185 °F (-20 ºC to 85 ºC) |
| Operating Temperature | 5 % to 95 % |
| Power Supply | 5 V |
| Display | Two LED indicators (Red For Mains, Green For Status) |
| Remark | With Buzzer |
| Read ID Numbers | 10 Numbers (18 numbers is optional) |
| Size | 3.70 in × 2.36 in × 0.39 in (94 mm × 60 mm × 10 mm) |
| Weight | 3.53 oz (100 g) |
