Technical Specifications
| Supported Protocols | IEEE802.3,IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE802.1q, IEEE802.1p, IEEE802.1z, IEEE802.1d, IEEE802.1s, IEEE802.1w, IEEE802.1ax, IEEE802.1ak |
| Maximum Frame Length | 10K |
| Number of Ports | 12 10 or 100 or 1000M RJ45 ports, 12 100M or 1000M SFP optical ports, 1 Console port |
| VLAN Address Table | 4K |
| MAC Address Table | 8K |
| Cache | 4Mbits |
| Transmission Rate | 10 Mbps or 100 Mbps or 1000 Mbps |
| Communication Mode | Full-Duplex and Half-Duplex |
| Function | LACP, QoS, SNMP, Stackable, VLAN Support |
| Switch Capacity | 52Gbit |
| Ports | 12LAN 12SFP |
| Filter and Forward Rate | 10Mbps：14880pps |
| 100Mbps：148800pps | |
| 1000Mbps：1488000pps | |
| MTBF | ＞100,000 hours |
| Applications | CCTV Security System |
| Fiber Port | 12 x 1000M SFP |
| PoE Ports | 1 to 12 Port Support PoE |
| Storage Humidity | 0% to 90% non to condensing |
| Power Supply | AC 220 V or DC to 48 V (power supply optional), support power redundancy backup |
| Power Consumption | max 25W |
| Storage Temperature | 104 °F to 185 °F (40 ⁰C to 85 ⁰C) |
| Appearance Structure | 19.09 in x 7.87 in x 1.77 in (48.5 cm x 20.0 cm x 4.5 cm) |
| Weight | 8.16 Ibs (3.7 kg) |
