Features
- High-Frequency RFID Electronic Tag Reader.
- Supports M 1, S 50, S 70, and ISO 14443-A type tags.
- Compact Product Size.
- Communication via USB and UART TTL Interfaces.
- Operating Frequency of 13.56 MHz.
- Humidity tolerance up to 95% RH.
- Power Supply requirement of DC 5 V.
Technical Specifications
| Frequency | 13.56 MHz |
| Supported Tags | M 1, S 50, S 70, ISO 14443-A Type |
| Interfaces | USB and UART-TTL |
| Power Supply | DC 5 V |
| Humidity Tolerance | ≤ 95% RH |
| Protocol | ISO 14443-A |
| Temperature | -13 °F to 158 °F (25 C to 70C) |
| Dimension | 1.30 in X 0.91 in X 0.39 in (33 mm X 23 mm X 10 mm) |
| Weight | 7.05 oz (200 g) |
