Overview
Specimen Track 12G-SDI Fiber Converter with 4K 60Hz Support and 11.88 Gb Bandwidth Over Fiber. It is compatible with 12 G to SDI, 6 G to SDI, 3 G to SDI, HD to SDI, SD to SDI, ASI, TS stream (auto switching) and SMPTE 292M, 259M, 296M, 297M, 372M, 424M, 425M, 2081, 2082.
Features
- 12G-SDI Fiber Saver
- 1 SFP Slot
- Multiple SDI Formats
- SMPTE Compatibility
- Rack Mountable
Technical Specifications
| Video Channel | 1 optional |
| Reflection Loss | >15 DB |
| Output Number | 1 |
| Wavelength | 1310 nm or 1550 nm |
| Operating Temperature | 32 °F to 122 °F (0 ℃ to +50 ℃) |
| Input Channel | 1 input with loop |
| Output Channel | 2 |
| Signal Level | 800 mV nominal |
| Raise Or Fall Time | 34.2 ps nominal |
| Connector | 75 Ω BNC |
