Technical Specifications
| Light source | Infrared (905 nm) |
| Laser safety level | Class I (GB 7247.1 to 2012, human eyes safety) |
| Scanning angle range | 270° |
| Sampling frequency | 15 Hz to 25 Hz |
| Scanning angle resolution | 0.5° |
| Sensing range (with 70% reflection） | 0.3 ft to 16.4 ft (0.1 m to 5 m) |
| Sensing range (with 10% reflection） | 0.3 ft to 6.6 ft (0.1 m to 2 m) |
| Function | Obstacle avoidance |
| Working environment | Indoor |
| Measurement error | 0.39 in (1 cm) 0.79 in (2 cm) |
| Communication | Type-C or RS 485 |
| Input | IO（6） |
| Output | IO（4） |
| Number of channels | 64 |
| Indicator light | 4 |
| Start Time | 10 sec |
| Response time | 50 ms |
| Operating Voltage | DC 9 V to 28 V |
| Power consumption | 5 W |
| Enclosure rating | IP 67 (GB 4208 to 2008) |
| Ambient light | 80,000 lux |
| Working temperature | 32 °F to 122 °F (0 ℃ to 50 ℃) |
| Storage temperature | -4 °F to 158 °F (-20 ℃ to 70 ℃) |
| Dimension | 2.4 in x 2.4 in x 2.8 in (60 mm × 60 mm × 72 mm) |
| Weight | 0.55 lb (250 g) |
