Overview
The Specimen Track Long Distance Detection Sensors are a 270° scanning lidar based on TOF technology, which can match better with small space conditions with smaller size than such as being used on small robots and AGV. It can be used in the fields of indoor robot navigation, route planning, contour detection and security. The product uses infrared invisible pulse laser with meeting the safety requirements of CLASS-1 human eyes and has the characteristics of smaller size, lower power consumption and easier installation.
Features
- Ranging method based on TOF
- 270° detection for object distance and angle
- Detection ranges up to 787 in (20m)
- Small size
- Wide voltage supply range
- 86400 points per second
- Customizable data format
Technical Specifications
| Voltage | 9 V to 28 V |
| Wavelength | 905 nm |
| Scanning Angle | 270 º |
| Angle Resolution | 0.25 º |
| Measuring Rate | 86400 Hz |
| Scanning Rate | 20 Hz |
| Accuracy | 0.02 m |
| Range Measurement | 8m, 10% |
