Overview
Specimen Track proximity Lidar sensor employs the DTOF (direct time-of-flight) ranging principle. In contrast to laser radar systems based on triangulation ranging, this sensor offers a broader ranging range and is less susceptible to interference from external ambient light. With a data sampling rate of up to 18 kHz, it provides enhanced data support for detection decisions within the same time frame.
Features
- High data sampling rate
- Realistic view of smooth glass
- Built in brush less motor
- High quality point cloud
- High data Sampling Rate
- 270 horizontal angle of view scanning Lidar
Technical Specifications
| Scanning Principle | Mechanical Rotation |
| Theory | DTOF, Rotating Mirror Type |
| Output | UDP/USB |
| Range | 0 in to 1574.8 in (0 m to 40 m) |
| Detection Range | 270° |
| Distance Resolution | 0.39 in (1 cm) |
| Range Accuracy | 0.78 in (2 cm) |
| Data Sample Rate | 45kHz |
| Laser Class | Class 1 Eye Safe |
| Wavelength | 940 nm |
| Environmental Protection | IP65 |
| Operating Voltage | 9 V to 36 V |
| Power Consumption | ≤2W |
| Storage Temperature | -40 °F to 167 °F (-40°C to 75 °C） |
| Operating Temperature | -13 °F to 140 °F (-25 °C to 60 °C） |
| Weight | 0.35 lb (160 g) |
| Dimension | 2.36 in x 2.36 in x 3.14 in (60 mm x 60 mm x 80 mm) |
