Features
- Long measurement distance, high measurement accuracy, high horizontal resolution
- Vehicle design standards, stable structure, lower power consumption
- Easier to mass produce and cost-effective
Technical Specifications
| Scan Channel | 32 |
| Wavelength | 905 nm |
| Accuracy | 2 cm |
| Scanning Frequency | 5Hz, 10Hz, 20Hz |
| Horizontal Field of View | 120 º |
| Vertical Field of View | -6.67 º to 4.58 º |
| Power Supply Range | 9 V to 36 V |
| Power Consumption | 100 W |
| Shock | 500m/ sec2, 3G rms |
| Temperature | -4 ºF to 149 ºF (-20 ºC to 60 ºC) |
| Size | 6.1 in x 4.2 in x 3.5 in (155 mm x 107.5 mm x 90 mm) |
| Weight | 3.3 lb (1.5 kg) |
