Overview
Specimen Track omni-directional ultra-wide-angle LiDAR sensor used to accelerate high performance mobile robots into the public life of the goal. It accelerates the process of the era of mobile intelligence. Take technological innovation as the cornerstone to optimize and improve the process and cost. It has omnidirectional ultra-wide angle scanning capability, minimal blind area and stable operation to enable infinite scenes.
Features
- Omni-directional ultra-wide angle bionic 4D laser radar
- Compact size
- Highly transparent object detection
- Anti ambient light
- Non repetitive static scanning
- Dynamic scanning at close range
Technical Specifications
| Scanning distance | 98.4 ft (30 m) 90% reflectivity 32.8 ft (10 m) 10% reflectivity |
| Measurement accuracy | +0.8 in (2.0 cm) |
| Nearby blind area | 0.16 ft (0.05 m) |
| Sampling frequency | 43200 points/s |
| Effective frequency | 21600 points/s |
| Circumferential scanning frequency | 11 Hz |
| Vertical scanning frequency | 180 Hz |
| Communication interface | TTL UART |
| IMU | 3 axis acceleration, 3 axis gyroscope |
| Human eye safety level | Class 1 |
| 4D data | 3D position, 1D grayscale |
| Antiglare capability | >100 Klux |
| Power | 6 W to 12 W |
| Size | 2.95 in x 2.95 in x 2.56 in (75 mm x 75 mm x 65 mm) |
| Weight | 0.5 lb (230 g) |
