Technical Specifications
| Ranging distance | 0.1 m to 40 m |
| Laser frequency | 9.2 KHz, 16.2 KHz |
| Scanning frequency | 7 Hz to15 Hz |
| Echo intensity | 0 to 254 |
| Working voltage | 5.1 VDC ±0.2 V |
| Horizontal field of view | 360° |
| Horizontal angle resolution | 0.4° 10 Hz, 0.23° 10 Hz, 0.26° -0.6°, 0.34° 15Hz |
| Ranging accuracy | ±1.18 in (±30 mm) |
| Distance resolution | Mm |
| Port | Serial Port UART 3.3 V |
| Anti-glare | >80000 LX |
| Power | ≤2 W |
| Protection level | IP 5X |
| Equipment size | 2.16 in × 2.16 in × 2.01 in (55 mm x 55 mm x 51 mm) |
| Working temperature | -14°F to 122 °F (-10 °C to +50 °C) |
| Reference weight | 0.24 lb (108 g) |
