Features:
- 10/100/1000Mbps electrical/optical port (dual optical and dual electrical)
- Excellent innovative ergonomic design, easy to carry
- Equipped with a wrist strap and bracket for easy operation in various environments
- 5-inch LCD color touch screen, intelligent navigation menu
- Graphical and numerical display of test results
- RFC2544 automatic testing for fast network testing and fault finding
- Complete Y.1564 testing
- LED indicator light, screen display characters and icons for operators to understand the current work status
- Large capacity memory to store setting information and test results
- Instrument-embedded software can be easily upgraded
- L1/L2/L3/4BER testing
- Complete RFC2544 testing: throughput, packet loss rate, latency, back-to-back
- Multi business testing (10 streams)
- Support for receiving end traffic filtering statistics
- Support LAN testing
- Connectivity testing: PING, TRACE ROUTE, IP scanning
- Supports statistics such as frame length, frame type, and utilization in pass and terminal modes
- Optical power test, temperature, working current and working voltage test of optical module
- Virtual cable testing (vCT: identifying cable short circuits, open circuits, and cable length information)
- Service interruption time test
- Provide testing functions such as port positioning, packet capture, and loopback
- Jitter test
Technical Specifications:
| Optical Interface | Two GigE interfaces |
| Wavelength | 850 nm |
| Laser type/ Connector/ transceiver type | VCSEL/LC/SFP |
| Test Items | |
| Y.1564 | Perform network configuration and service testing according to ITU. T Y.1564. Remote loopback or dual testing device mode can be used for testing to obtain bidirectional results. |
| RFC2544 | According to RFC 2544, it can measure throughput, back-to-back, frame loss, and delay. Frame size: RFC defined size; user can configure 1 to 7 types. |
| BERT error code test | Whether with or without VLANQ-inQ, it can support layers 1 to 4. |
| Through mode | Segmentation of information flow between service provider network and customer resident equipment. |
| Service interruption time (SDT) | Including statistical data, such as minimum interruption time, maximum interruption time, last intermediate time, average interruption time, total interruption time, and threshold for passing through. |
| Multi-stream generation | Capable of transmitting and monitoring up to 16 data streams on Ethernet and IP networks. |
| Information flow generation and monitoring | It can generate information flow and monitor Ethernet and IP information flow, and can shape information flow according to the following statistical data: throughput, frame loss, frame ordering, packet jitter, delay, frame size, information flow type, and stream child monitoring. |
| VLAN stacking | It can be used on any stacked VLAN layer. Generate data streams with up to 2 VLAN layers (including VLANs labeled with IEEE802.1ad Q-in-Q) based on VLAN ID or priority. |
| General Indicators | |
| Test interface | Dual RJ45 ports: 10/100/1000 BASE-T Dual SFP port: 1000BASE-SXLXZX |
| Supported Standards | IEEE 802.3, RFC3393, RFC2544, Y.1564 |
| Data Interface | RJ-45/USB |
| LED Status/ Alarm indication | POWER, ALARM |
| Display | 800 × 480 color LCD touchscreen |
| Power Supply Method | Lithium battery and power adapter |
| Battery Usage Time | Continuous operation for more than 4 hours |
| Relative Humidity | 0 % to 95 % (No condensation) |
| Operating Temperature | 32°F to 122°F (0°C to 50°C) |
| Dimensions (Length × Width × Height) | 7.48 in x 5.11 in x 2.55 in (19 cm × 13 cm × 6.5 cm) |
| Weight | 28.21 oz (800 g) |
