Features
- It has both RS232 and RS485 communication modes;
- Supports external handheld operation panel for calibration and parameter setting;
- Aluminum alloy housing to give the product strong anti-interference ability;
- Supports Modbus-RTU protocol;
- Mature filtering algorithm gives the product higher accuracy;
- The conversion speed can reach up to 128OHZ;
- Optional analog (±1OV and 4-2OmA) output and IO (1 input 2 output).
Technical Specifications
| Parameters | Details |
| Input range | O.4 to 6mV/V |
| Display accuracy | 1/10000 |
| Sensor excitation voltage | 5VDC±2%，100mA |
| Power supply | DC:15V to 30V |
| Input load | 6pcs sensors of 350 to 1000Ω |
| Operating temp. range | -30 to 60℃ (-22 to 140°F) |
| Withstand voltage | 2000V AC50/60HZ per min |
| A/D performance | 24bit, Delata-Sigma |
| Output supply | 10/40/640/1280/4800t/s |
| Surrounding environment | Ambient temperature: 10 to 55℃ ；storage temperature: -25 to 65℃ Ambient temperature: 14 to 131°F ；storage temperature: -13 to 149°F |
| Ambient humidity | 35 to 85%RH ；storage humidity：35 to 85%RH |
| Interface | RS485/232（0 to ±10V/ 0 to ±5V/0 to 20mA/4 to 20mA） |
