Features
- Ion Selective Electrode
- Automatic Compensation
- Immersion Installation
- Automatic Cleaning
Technical Specifications
| Measuring Principle | Ion selective electrode method(ISE).pH and temperature automatic compensation, potassium ion manual compensation. |
| Measuring Parameters | Ammonia nitrogen 0 mg/L to 100 mg/L or 0 mg/L to 1000 mg/L. pH 4 to 10 |
| Communication Mode | RS485(Modbus RTU) |
| Installation | Immersion/input installation |
| Protection Grade | IP68.The deepest depth is 10 meters. |
| Power Supply Voltage | 12 V DC, current <50 mA |
| Probe Cable Length | 10 meters |
| Cleaning Method | Automatic cleaning brush.Cleaning interval can be arbitrarily set. |
| Sensor Size | 2.52 in x 10.67 in (6.4 cm x 27.1 cm) |
| Measuring Accuracy | Ammonia nitrogen ±10% measurement value or ±0.5 mg/L, take a larger value. pH: ±0.1. |
| Communication | RS485 (Modbus RTU) |
| Life Span of Ammonium Ion Electrode | 6 to 12 months (depending on the water quality) |
| Life Span of pH Electrode | 6 months |
