Technical Specifications
| Communication | Mbus, RS485, LoRa, NB-IoT, Sigfox |
| Material | Cast Steel |
| Color | Black |
| Standard | ISO4064 Class B |
| Dynamic Range | R125-R500 |
| Pipe Material | Cast Iron |
| Metrological Class | Class 2 |
| Ratio (Q3/Q1) | R125, R200, R250, R500 |
| Max Admissible | 1.6 MPa |
| Pressure Loss | ΔP < 40 kPa |
| Flanged Standard | ANSI, GB (DIN) |
| Pressure Stage | PN16 |
| Installation Position | U10 / D5 |
| Protection Class | IP65 / IP68 |
| Battery Lifespan | 3.6 VDC lithium battery, 6 / 10 / 16 years |
| Data Storage | 24/120 logs (daily, weekly, or monthly) |
| Electromagnetic Class | E1 |
| Mechanical Class | M1 |
| Environmental Condition | B |
| Interface & Communication | IrDA, LoRaWAN, Sigfox, NB-IoT, W-MBus, RS485, MBus, Pulse Output |
| Assembly Orientation | Horizontal, Vertical |
| Display & Indication | Units: m³ or Gallon (optional); 9-digit LCD display |
| Temperature | Medium: 41°F to 131°F (0.1°C to 30°C or 50°C) (T30/T50); Ambient: 5°C to 55°C (); Storage: -4°F to 140°F (-20°C to 60°C) |
| Size | DN50 to DN900 (1.97 in to 35.43 in (5 cm to 90 cm) |
