Technical Specifications
| Chipset | SX 1276 |
| Type | BLE Module |
| Function | IOT System |
| Bluetooth Protocol | Bluetooth 5.0 |
| LoRaWAN Protocol | LoRaWAN 1.0.2 B |
| LoRaWAN Band | US 915, AU 915, EU 868, EU 433, AS 920 923, AS 923 925, RU 864, ID 920, KR 920, IN 865, KZ 865, CLAA, CN 470, CN 470 Ali |
| LoRa Maximum RF Power | 20 dBm |
| LoRa Sensitivity | -139 dBm at SF 12, BW 125 kHz, 434 MHz or 470 MHz – 137 dBm at SF12, BW 125kHz, 868 MHz or 915 MHz |
| Access Quantity | Greater than 500 in one LoRa gateway |
| Data Rate (bps) | 300 to 30 K |
| Beacon Access Quantity | 100 beacon messages can be received within 1 s, Maximum of 15 beacon messages at one single LoRa communication |
| Peak Current | Max 140 mA in transmit mode |
| Ingress Protection | IP 66 |
| Encryption | AES 128, X 509 |
| Standby Time | 2552 days, Bluetooth receiving windows 3 seconds, Positioning interval 5 minutes (300 s), Average data size around 12 beacons (5.5 bytes per beacon, 800 ms beacon advertise interval), Use commands to change the period of position report to save power |
| Battery | 5,300 mAh |
| Battery Life | Adjustable Position Report Interval 5 s x n (1 to 65536), Heartbeat Report Interval 30 s x n (1 to 65536), Switch Mechanical Customized data filter and data report, Support FOTA over Bluetooth Support, Max Beacons Supported 105, maximum of 15 beacon messages at one single LoRa communication at SF9 |
| Operating Temperature | -40 °F to 185 °F (- 40 ℃ to 85 ℃) |
| Dimension | 6.3 in x 6.3 in x 2.17 in (16 cm x 16 cm x 5.5 cm) |
| Weight | 5.29 oz (150 g) |
| Positioning Precision | 9.84 ft (3 meters) |
