Bluetooth Beacon with BLE , nRF52810 Chipset, 164 ft Range, and AES Security – Specimen Track

Bluetooth beacon with BLE, 164 ft range, AES security, and CR 2032 battery. Ideal for precise indoor navigation and monitoring.

SKU: STRBB-126 Category:

Overview

Specimen Track temperature and humidity sensor beacon is a new generation sensor technology which is based on Beacon. This product can send collected data to phone or gateway via Beacon broadcasting.



Technical Specifications

Bluetooth versionBLE 5.0
Searching distance164 ft (50 m)
Connecting distance32.8 ft to 98.4 ft (10 m to 30 m)
Power supplyCR 2032 button cell
ChipsetnRf52810
Working currentAbout 235 ua
Operation frequency2400 MHz to 2483 MHz
Frequency error+/- 20 KHz
Standby current46 ua
Output power0 dBm
Receiving sensitivity-93 dBm
Antenna50 ohm
Operation voltage2 V to 6 V DC
Security processorAES 128 bit
Temperature measure range-40 °F to 185 °F (-40 °C to 85 °C)
Size1.6 in x 0.6 in (40 mm x 14 mm)

Click Here to Download Technical
Documentation (User Manual or Instruction Manual)
