Technical Specifications
| Aggregate Throughput | 50 Mbps to 100 Mbps |
| Total onboard WAN or LAN 10 ports or 100 ports 1000 ports | 2 |
| RJ–45–based ports | 2 |
| SFP-based ports | 1 |
| Enchanced sevice-module | 0 |
| Doublewide service-module | 0 |
| NIM slots | 2 |
| OIR (all I/0 modules) | yes |
| Onboard ISC slot | 1 |
| Default memory double-data-rate 3 (DDR3) error-correction-code (ECC) DRAM (Combined control or services or data planes) | 4 GB |
| Maximum memory DDR3 ECC DRAM (combined control or services or data planes) | 8 GB |
| Default memory DDR3 ECC DRAM (data plane) | NA |
| Maximum memory DDR3 ECC DRAM (data plane) | NA |
| Default memory DDR3 ECC DRAM (control or services plane) | NA |
| Maximum memory DDR3 ECC DRAM (control or services plane) | NA |
| Default Flash memory | 4 GB |
| Maximum Flash Memory | 8 GB |
| External USB 2.0 slots (type A) | 1 |
| USB console port -type B mini (up to 115.2 kbps) | 1 |
| Serial console port – RJ45 (up to 115.2 kbps) | 1 |
| Serial auxiliary port – RJ45 (up to 115.2 kbps) |
1 |
| Power-supply options | External: AC and PoE |
| AC input voltage | 100 V to 240 V AC Auto ranging |
| AC input frequency | 47 Hz to 63 Hz |
| AC input current range, AC power supply (maximum) | 1.5 A to 0.6 A |
| AC input surge current | 90 A peak and less than 3 Arms per half cycle |
| Typical power (no modules) (watts) | 36 W |
| Maximum power with AC power supply (watts) | 125 W |
| Maximum power with PoE power supply (platform only) (watts) | 260 W |
| Maximum endpoint PoE power available from PoE power supply (watts) | 120 W |
