| Polarity |
Break over, short circuit, open circuit, dislocation |
| Leakage Current |
Setting Range: 0.5 mA, 1.0 mA, 2.0 mA, 3.0 mA, 5.0 mA, 10 mA |
| Internal High-Voltage Output |
0 V to 5000 V Adjustable |
| External High-Voltage Output |
0 V to 5000 V Adjustable |
| Operating Voltage |
220 Vac, 12 A, 50 Hz / 60 Hz |
| Voltmeter Range |
0 V to 5000 V |
| Voltmeter Resolution |
0.5 level |
| Insulation Voltage |
Output Voltage: DC500V |
| Insulation Resistance Range |
2 MΩ, 7 MΩ, 20 MΩ, 50 MΩ, 100 MΩ, 200 MΩ |
| Insulation Resolution |
0.5 level |
| Voltage Withstand Time |
Timing Range: 0.1 to 99.9 seconds Minimum time for item measuring: 0.3 seconds |
| Wire Sensitivity |
> 10 pF |
| Barometric Pressure |
< 56.88 psi (< 4 kgf/cm²) |
| OK Product Handling |
Automatic printing, push out, counting, indicator n |
| NG Product Handling |
Automatic locking, counting, indicator ON, buzzer alert |
| Other Functions |
Automatic cutting of defective products, voice prompts, light alarms |
| Safety Features |
Electric leakage, short circuit, overheating protection |
| Size |
28.74 in x 20.87 in x 19.69 in (73 cm x 53 cm x 50 cm) |
| Weight |
176.37 lbs (80 kg) |
