Features
- Wide Measurement Range
- Adjustable Test Currents
- High Measurement Accuracy
- Continuous Working Mode
- Clear LCD Display
Technical Specifications
| Measurement Range | 1 mΩ to 1999 mΩ |
| Resolution | 1mΩ (0.001 Ω) |
| Test Current | DC 1A, 2A, 5A, 10A Four fixed current gears |
| Measurement Accuracy | ±(0.5% + 2d) |
| Measurement Radius | 164.04 ft (50 m) |
| Display Mode | 3 1/2 LCD Display |
| Working Mode | Continuously |
| Work Power Supply | AC 220V ±10%, 50Hz |
| Working Environment | 14 °F to 104 °F (-10 °C to 40 °C) |
| Dimensions | 11.81 in x 10.63 in x 7.87 in (30 cm³ x 27 cm³ x 20 cm³) |
