Overview
Specimen Track Desktop Mini RFID USB Reader is a high-performance, lower-price 125khz or 13.56MHz RFID reader, a reader distance of up to 1.18in to 0.31in (3cm to 8cm), widely used for RFID Radio Frequency Identification systems and projects, such as Automated parking management systems, Personal identification, Access controller, Production Access control, etc. Specimen Track Desktop Mini RFID USB Reader readers are smart modules without touching based on international standard agreement ISO14443A or B, ISO15693. Specimen Track Desktop Mini RFID USB Reader is equipped with a high-capability chip, processor, security, and electric monitor. The reader can communicate with the PC using the interface. Specimen Track Desktop Mini RFID USB Reader is of high capability, anti-jamming, small size, and good quality, which brings more convenience.
Features
- Mini RFID reader
- Card number issuing device
- Support reading the first 10 digits or the last 8 digits
Technical Specifications
| Frequency | 125KHz or 13.56MHz or Dual frequency |
| Size | 4.33in X 3.23in X 0.94in (110mm x 82mm x 24mm) |
| Voltage | DC12V |
| Static Current | Less than 50mA |
| Reading Distance | ID: 1.18in to 5.90in (3cm to 15cm) or IC: 0.79in to 3.15in (2cm to 8cm) |
| Temperature | -13°F to 185°F (-25ºC to 85ºC) |
| Reader Speed | Less than 0.2sec |
| Humidity | 10% to 90% |
| Support | 125KHz EM ID or 13.56MHz MF IC or Dual frequency at the same time |
| Card Type | EM-ID card, Middle distance ID card, General ID card, Dual frequency card |
| Interface | USB |
| Built-In | Antenna, speaker, buzzer, red (blue) green color LED |
| Transmission | USB |
| Supporting System | Compatible with Windows98, 2000, XP |
| Special Provide | Logo printing, long cable, Reader module, Dual frequency (ID&IC) |
| Application | For access control, attendance, fees, patrol, card, building on say, parking systems, highways, and RFID outdoor applications. |
