Overview
Specimen Track Compact Outdoor LoRaWAN Gateway: Versatile IoT Connectivity with 4G and Wi-Fi is an open-source solution that connects LoRa wireless networks to IP networks using Wi-Fi, Ethernet, or 4G cellular connections. This device supports Semtech packet forwarding, fully compatible with the LoRaWAN protocol, making it a robust option for integrating existing IoT services. It includes the SX1302 LoRa concentrator with 10 programmable parallel demodulation paths and supports various frequency bands for global use. With automatic preset configurations, this gateway is designed for large-scale deployments and long-term maintenance.
Features
- Connects LoRa to IP networks
- Supports Wi-Fi, Ethernet, 4G
- Fully compatible with LoRaWAN protocol
- 10 programmable demodulation paths
- SX1302 LoRa concentrator
Technical Specifications
| LoRa Interface | 1 x SX1302 + 2 x SX1250 LoRa transceiver |
| Maximum Output Power | 27 dBm |
| Sensitivity | -140 dBm |
| PoE Port | 10 M / 100 M RJ45 |
| Wi-Fi | 1 x 2.4 G (802.11 bgn) |
| USB Host Port | 1 x USB |
| Mini PCIe Interface | 1 x Mini PCIe |
| Power Input | 12 V, 2 A |
| LoRa Antenna Connector | RP-SMA |
