Features
- Frequency Supports both 125KHz and 13.56MHz
- Standard Compliant with ISO/IEC 14443-A/B, ISO/IEC 15693, ISO 18092
- Supported Card Types Includes 1K, 4K, Ultralight, I.CODE SLI, etc
- Interface Offers RS232, USB, TCP/IP, and WIFI connectivity options
- Read Distance Greater than 5 cm, though actual distance depends on tags
- Indicator Equipped with 2 LEDs and 1 buzzer for feedback
- Dimension Physical dimensions are 100x100x27mm
Technical Specifications
| Frequency | 125KHz and 13.56MHz |
| Standard | ISO or IEC 14443-A or B, ISO or IEC 15693, ISO 18092 |
| Supporting Card | NFC. S50 or S70 or Ultralight, Pro, AT88RF020, 66CL160S, SR176, SRIX4K, I-code 2,TI RFID Tag-it HF-I. |
| Interface | RS232, USB-UART, USB, TCP or IP(POE)+WIFI |
| Power Supply | 5V or 12V |
| Read Distance | > 1.97in (5cm) (Depend on tags) |
| Baud Rate | 9600 to 115200bit or bits (Configurable, default 9600) |
| Operating Temperature | 14°F to 158°F (-10℃ to 70℃) |
| Sheathing Material | ABS |
| Dimension | 4.64567in x 2.99213 x 0.86614in (118mm x 76mm x 22mm) |
| Weight | 7.75ounces (220g) |
