Overview
RFID reader supports 125 KHz or 13.56 MHz with 3.3 V to 5 V power, 0 to 1.96 of reading distance, compact design, supports M 4200 or TK 4100.
Technical Specifications
| Frequency | 125 KHz and 13.56 MHz |
| Power Supply | 3.3 V to 5 V |
| Supporting Card | EM 4200 or TK 4100 or Mi S50 or S70 or Ultralight |
| Current | < 70 mA |
| Reading Distance | 0 in to 1.96 in (0 cm to 5 cm) |
| Interface | TTL, WG-26, WG-34 and USB |
| Standard | TLL and USB |
| Protocol | ISO 14443–A |
| Operating Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Storage Temperature | -4 °F to 176 °F (-20 °C to 80 °C) |
| Dimension | 1.96 in x 1.18 in x 0.35 in (50 mm x 30 mm x 9 mm) |
| Weight | 0.04 lb (0.02 kg) |
