Features
- Card type of 125 KHz and 13.56 MHz
- Interface Wiegand 26 or Wiegand 34, RS 232, RS 485
- Support cards of EM 4100, ISO 14443 A and ISO 14443, ISO 15693 and ISO18092
- Current less than 50 mA
- Power Supply of 9 V or 12 V
Technical Specifications
| Frequency | 125 KHz and 13.56 MHz |
| Reading Distance | > 0.26 ft (7.92 cm) |
| Interface | Wiegand 26 or Wiegand 34, RS 232, RS 485 |
| Power Supply | DC 9 V to 12 V |
| Current | <50 mA |
| Protection Level | IP65 epoxy resin embedding |
| Humidity | 0 % RH to 95 % RH |
| Protocol | ISO 14443 A or ISO 14443 B, ISO 15693 and ISO 18092 |
| Operating Temperature | 14 °F to 158 °F |
| Storage Temperature | − 4 °F to 176 °F |
| Dimensions | 4.37 in x 2.76 in x 0.55 in (111 mm x 70 mm x 14 mm) |
