Features
- Innovative CPU+NP architecture for efficient L3 to L7 service processing
- Delivers superior performance compared to industry average
- Ensures smooth operation of critical applications
- Optimizes bandwidth usage by reaching up to 90% efficiency
- Integrates SD WAN, cloud management, routing, switching
- Utilizes application to based intelligence for optimal routing decisions
- Plug to and to play deployment with automated provisioning
- Simplifies network setup and minimizes ongoing maintenance expenses
Technical Specifications
| Network | Wireless Lan, Wired LAN |
| Memory | 2 GB |
| Wi-Fi | Dual To Band (2.4 GHz And 5 GHz), 802.11b Or g Or n Or ac |
| DSP (Voice) | Built To In 64 To Channel Voice |
| Long To Term Operating Relative Humidity | 5% To 95%, Noncondensing |
| Forwarding Performance (LAN -> WAN + WAN -> LAN, NAT + ACL + QoS, IMIX) | 2 Gbit Or s |
| IPsec Performance (IMIX) | 2 Gbit Or s |
| Fixed WAN Ports | 1 x GE Combo, 1 x GE RJ45, And 1 x 10 GE SFP+ (Compatible With GE SFP) |
| Fixed LAN Ports | 8 x GE RJ45 (Can Be Configured As WAN) |
| SIC Slots | 2 |
| USB Port | 1 x USB 3.0 (Compatible With USB 2.0) And 1 x USB 2.0 |
| CPU | 1.4 GHz, 4 Cores |
| Maximum Power Consumption | 30 W |
| Auxiliary Or Console Port | 1 x RJ45 Console Port |
| Flash Memory | 1 GB Or 512 MB |
| Rated Input Voltage | 100V To 240V, 50 Hz To 60 Hz |
| Input Voltage Range | 90V To 264V, 47 Hz To 63 Hz |
| Maximum Input Current | 2 A |
| Maximum Output Power | 60 W |
| Dimensions Without Packaging | 1.75 in x 15.35 in x 9.05 in (0.44 cm x 39.0 cm x 22.98 cm) |
| Storage Temperature | 40 °F To +158 °F (-40 °C To +70 °C) |
| Long-Term Operating Temperature | 32 °F To 113 °F (0 °C To 45 °C) |
| Weight Without Packaging | 6.39 lb (2.9 kg) |
