Technical Specifications
| Use | FTTx |
| Display | High resolution 7 in (177.8 mm) color LCD display with LED backlight |
| Storage | 1000 test result |
| Type | Data Integrated Network Tester |
| Operating Temperature | 32° F to 122° F (0° C to 50° C) |
| Storage Temperature | -4° F to 158° F (-20° C to 70° C) |
| Temperature | 5% to 90% non-condensing |
| Internal Battery | lithium battery 8000 Ma, 12.6 V |
| Battery Operation Time | 4 hrs |
| Charging Time | 5 hrs |
| Charger | 12 6 V at 3 A, 90 to 265 vac, 50 Hz to 60 Hz |
| Dimension | 9.1 in x 5.1 in x 2.4 in (230 mm x130 mm x 60 mm) |
| Weight | 5.5 lb (2.5 kg) |
