Factory Direct Temperature Data Logger with Thermal Printing - Specimen Track
Factory Direct Temperature Data Logger with Thermal Printing - Specimen Track - Image 2

Factory Direct Temperature Data Logger with Thermal Printing – Specimen Track

Explore Factory Direct Temperature Data Loggers with thermal printing capabilities for accurate temperature monitoring. Ideal for various industries.

SKU: STRRNBDL-106 Category:

Features

  • Channels: Up to 16 max
  • Measurement Range: 0-9999
  • Weight: 4.41 lbs (2 kg)
  • Processor: ARM Cortex-M3 32-bit
  • Storage: 64MB-248MB Flash
  • Data Backup: USB 1.1/2.0 (1GB-32GB)
  • Distribution Output: Up to 3 transmitters
  • Transmitter Output: 4 channels, max 750Ω
  • Relay Alarm Output: Up to 6 relays
  • Communication: RS232, RS485, Modbus RTU
  • Print Interface: RS232C, 1200 baud
  • Recording Interval: 1-240s, 11 file options
  • Power Failure Protection: Permanent data storage
  • Clock Protection: Hardware clock for accuracy
  • Humidity: 0%-85% (No condensation)
  • Altitude: <2000m (6561.68 ft)
  • Net Weight: ≤3.31 lbs (1.5 kg)
  • Cold End Compensation: ±2°C (±3.6°F)
  • Operating Temperature: 14°F to 122°F (-10°C to 50°C)



Technical Specifications

Material ABS
Color 17.78 cm (7-in) true color TFT LCD
Power Supply 100 to 240 VAC, 24VDC
Application Industrial
Function Record sensor data
Output Signal RS485 Optional
Relay Output 6-way
Accuracy Real-time display: ±0.2% F.S, Recall accuracy: ±0.2% F.S. (Thermocouple cold end error removal)
Channels Max 16 channels
Measurement Range 0 to 9999
Weight 4.41 lbs. (2 kg)
Screen 7 in (17.78 cm) true-color TFT LCD (800 x 480 dot matrix)
Processor High-performance ARM Cortex-M3 32-bit RISC core
Storage Module Parallel NAND FLASH chips for historical data, serial FRAM for key parameters
Distribution Output Supports up to 3 transmitters, isolated distribution 24VDC, each group ≤ 60mA
Transmitter Output Up to 4 channels standard current output, load capacity 750 Ω (max), long-distance signal transmission
Relay Alarm Output Up to 6 relay alarm outputs, contact capacity 1A @ 250 VAC / 1A @ 30 VDC (customizable)
Communication Interface RS232C and RS485, supports Modbus RTU protocol, multiple baud rates (1200 to 57600)
Print Interface RS232C direct connection to micro printer, baud rate 1200
Recording Capacity 64 / 128 / 192 / 248MB (flash capacity optional)
Recording Interval 1 to 240 seconds, divided into 11 files (1, 2, 4, 8, 12, 24, 36, 60, 120, 180, 240 seconds)
Data Backup And Transfer Supports USB 1.1 / USB 2.0, 1G to 32GB U disk
Power Supply AC 100-240V, 50/60Hz, DC 24V, 12V (specific power to be indicated when ordering)
Power Failure Protection Built-in memory protection, permanent storage after power off
Clock Protection Integrated hardware clock for accurate operation after power down
Relative Humidity 0% to 85% R.H (without condensation)
Altitude <(2000m) 6,561.68 feet (unless specified otherwise)
Instrument Net Weight ≤ (1.5 kg) 3.31 lbs
Thermocouple Cold End Compensation Error ±3.6°F (±2℃)
Operating Temperature 14 °F to 122 °F (-10 ℃ to 50 ℃)
