Features
- Large touch screen and shortcut keys, easy to operate
- Large-capacity polymer lithium battery, with superlong working hrs
- Intelligent testing, simple use, powerful function
- Media of Memory Card and SD card
- Able to meet FTTx testing needs Several wavelengths can be chosen
- Solid casing design, dustproof and shockproof
- Optical Time Domain Reflectometer
- More powerful performance, much easier operation
- To meet the needs on the wide range of measurement by FTTx
- Metropolitan Area Network, Backbone Network
Technical Specifications
| Display | 5.6 in (14.22 cm) LCD touch screen |
| Linearity | 0.05 dB |
| Loss Threshold | 0.05 dB |
| Loss Resolution Ration | 0.01 dB |
| Sampling Point | 32 K |
| Typical Real-time Refreshing Duration | 0.2 s |
| Memory Capacity of Trace | SD Card (4G) greater than 1000 pcs |
| Optical Interface | FC or UPC (PC, and are selectable) |
| Visible Failure Orientation VFL | Wavelength 650 nm |
| Network | Wireless LAN |
| Data Interface | USB interface, SD card interface |
| Dimension (W X H X D) | 5.90 in x 9.25 in x 2.59 in (150 mm x 235 mm x 66 mm) |
