Technical specifications
| Transducer frequency | About 380 KHz |
| Response time | About 50 ms |
| Switching frequency | ≤ 13 Hz |
| Type of output | D4: NPN NO / NC D5：PNP NO / NC |
| Working voltage | 10 V to 30 V DC ripple 10 % |
| Rated working current | 200 mA Passage/overload protection 2 x 100 mA, short-circuit/overload protected |
| Repeatability | ≤ 1% |
| Range adjustment | Adjust the farthest and nearest range through the adjusting line |
| Degree of protection | IP65 |
| Connection mode | H4 (4-pin) M12 connecting wire or 2 m PVC cable |
| LED yellow light | The yellow light of the switch status indicator flashes. The target is detected under the set status |
| LED red light | The red light is always on error Red light flashing: no target is detected in the set state |
| Detection range | 1.97 in to 19.69 in (5 cm to 50 cm) |
| Non-detection zone | 0 in to 1.97 in (0 mm to 50 mm) |
