Features
- Industrial grade ARM 9 processor, 300MHz frequency
- 128MB DDR3 SDRAM,128 Mflash
- Support 2 wire high-speed 10 or 100 M independent network interface
- Support 2 or 4 wire RS485 serial communication interface
- Built-in real-time clock (RTC),temperature sensor and independent hardware encryption circuit to protect user IP
- Built-rich communication protocol library to support the electricity IEC60870-101 or 103 or 104 protocol, support ProfiNET, EtherNet, BACnet, SNPx, Modbus TCP or IP, MQTT, OPC-IE and other communication protocols
- Built-in WEB server, support for remote development, configuration, commissioning and maintenance
- Achieve communication management, data gateway, data forwarding, protocol conversion, pre-processing and other functions
- CAN interface bidirectional optical isolation CAN2.0 interface standard
- Support all the way debug serial port, as well as WIFI wireless LAN or GPRS or 3G or 4G remote communications and other extensions
- Expandable 4 G to 128 G TF memory card
- Rugged metal shell and internal circuit “three defenses” treatment, especially for the harsh environment on site
Technical Specifications
| Network | RS 485 to Ethernet |
| Uplink Protocol | ProfiNET, EtherNet, BACnet, SNPx, etc |
| Downlink Protocol | Modbus RTU, Modbus TCP, Profibus-DP |
| Application | Smart Meter Data Transmission |
| Type | Modbus Gateway |
| System Connection Method | RJ 45, 4G, 3G, 2G, WIFI, etc |
| Total Port | 1 RJ 45 ports |
| Customization | 2 Ports and Modbus Protocol, etc |
| Protocol Support | Standard or Special Protocol |
| Other Function | Expandable 4 G to 128 G TF Memory Card |
