Features
- Support port bandwidth limit, port flow control, broadcast storm suppression
- Support Web, CLI, Telnet management functions;
- Power down alarm, loop alarm;
- Can support POE (POE+) equipment;
- Support port mirroring, support Syslog, support Ping command, etc.
- Support COS, DSCP, 8 queues, support WRR, SP, WFQ scheduling mode, policy QOS
- Support port traffic statistics and online upgrade
- Support STP/RSTP, MSTP, support EAPS, ERPS
- Support IGMP Snooping V1/V2/V3, support GMRP
- Supports manual aggregation and static/dynamic LACP protocol
Technical Specifications
| Supported Protocols | IEEE802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE802.1q, IEEE802.1p, IEEE802.1z, IEEE802.1d, IEEE802.1s, IEEE802.1w, IEEE802.1ax, IEEE802.1ak |
| Maximum Frame Size | 10K |
| VLAN Address | 4K |
| MAC Address | 8K |
| Buffer | 4Mbits |
| Backplane Bandwidth | 56Gbit |
| Filtering and Forwarding Rates | 10Mbps：14880pps |
| 100Mbps：148800pps | |
| 1000Mbps：1488000pps | |
| Storage Temperature | 104⁰F to 185⁰F (40⁰C to 85⁰C) |
| Working Temperature | 104⁰F to 185⁰F (40⁰C to 85⁰C) |
| Humidity | 0% to 90% non to condensing |
| MTBF | ＞100,000 hours |
| Power Supply | input DC 9 to 48 V or AC 9 to 48 V |
| Power Consumption | Maximum 17 W |
| Transmission Rate | 10 Mbps or 100 Mbps or 1000Mbps |
| Communication Mode | Full-Duplex and Half-Duplex |
| Switch Capacity | 56 G |
| Ports | ≤ 8 |
| Function | LACP, POE, QoS, SNMP, VLAN Support |
| Ports | 8 Ports |
| Uplink Ports | 4 Gb SFP |
| PoE Ports | 8 x 10 Mbps or 100 Mbps or 1000Mbps POE Ports |
| Appearance Structure | 5.2362 in x 4.7244 in 1.9685 in (13.3 cm x 12.0 cm x 5.0 cm) |
| Weight | 2.094 lbs (0.95 kg) |
