| Pulse Width |
3 ns, 5 ns, 10 ns, 20 ns, 50 ns, 100 ns, 200 ns, 500 ns, 1 μs, 2 μs, 5 μs, 10 μs, 20 μs |
| Testing Distance |
1.640 ft, 1.24 mi, 3.10 mi, 6.21 mi, 12.42 mi, 24.85 mi, 49.72 mi, 74.56 mi, 99.42 mi (500 m, 2 km, 5 km, 10 km, 20 km, 40 km, 80 km, 120 km, 160 km) |
| Measurement Time |
Use-defined (smart link); with real-time measurement function |
| Linearity |
≤0.05 dB/dB |
| Loss Threshold |
0.01 dB |
| Loss Resolution |
0.001 dB |
| Distance Resolution |
0.03 ft (0.01 m) |
| Sampling Resolution |
minimum 0.8 ft (0.25 m) |
| Sampling Point |
Maximum 128,000 points |
| Dynamic Range |
32/30dB |
| Color |
Blue, Orange, grey, black |
| OPM Test Range |
-70 to +10db or –50 to +26dB |
| Distance Accuracy |
±3.3 ft (1m) +measuring distance×3×10-5+sampling resolution) |
| Internal Visual Source |
10 mw, CW/2Hz |
| Stable Laser Source |
>-5 dBm |
| Data Storage |
80000 groups of curves |
| Interface |
3 USB port |
| Display |
7-inch capacitive touching screen |
| Battery |
7.4 V/6.6 Ah lithium battery, continuous 8-10 hours |
| Working Temp |
14 ℉ to 122 ℉ (-10 ℃ to + 50 ℃) |
| Storage Temp |
4 ℉ to 167 ℉ (-20 ℃ to +75 ℃) |
| Relative Humidity |
≤90 %, non-den |
| Dimension |
9.05 in x 7.28 in x 2.75 in (23 cm × 18.5 cm × 7 cm) |
| Weight |
3.30 lb. (1.5 kg) |
