| Display |
5-inch TFT-LCD touch screen for clear and intuitive operation |
| Battery Life |
Up to 6 hours of continuous testing with backlight off |
| Data Storage |
Internal memory capable of storing up to 40,000 test results |
| Interfaces |
Equipped with USB and LAN ports for data transfer and remote control |
| Pulse Widths |
Offers a range of pulse widths from 3 ns to 20 µs |
| Distance Range |
Supports testing distances from 328 ft to 149 miles (100 m to 240 km) |
| Sampling Resolution |
Minimum resolution of 0.16 ft (0.05 m) |
| Sampling Points |
Supports up to 128,000 sampling points for detailed analysis |
| Distance Accuracy |
±(3.28 ft + test distance × 3 × 10⁻⁵ + sampling resolution) [±(1 m + test distance × 3 × 10⁻⁵ + sampling resolution)] |
| Refractive Index Setting |
Adjustable from 1.2000 to 1.7000 in 0.0001 steps |
| Dynamic Range |
Wide dynamic range for accurate testing over long distances |
| Event Dead Zone |
Less than 2.62 ft (0.8 m) |
| Attenuation Dead Zone |
Less than 9.84 ft (3 m) |
| Wavelengths |
Supports multiple wavelengths for versatile testing |
| Connector Types |
Compatible with SC/PC, FC/PC, and LC/PC connectors |
| Light Source |
Integrated light source for added testing capabilities |
| VFL Power |
Built-in visual fault locator with high visibility |
| Operating Temperature |
14°F to 122°F (-10°C to 50°C) |
| Storage Temperature |
-4°F to 158°F (-20°C to 70°C) |
| Humidity |
0% to 95% non-condensing |
| Dimensions |
7.68 in x 5.55 in x 1.73 in (19.5 cm x 14.1 cm x 4.4 cm) |
| Weight |
Approximately 1.98 lbs (0.9 kg) |
