Features
- Alloy steel, nickel-plated, single point bending beam, hermetically welded, tension or compression
- Ingress protection (according to EN 60529): IP68
- Suitable for belt scales, hopper
Technical Specifications
| Output resistance | 350 ± 3 Ω |
| Input resistance | 404 ±15 Ω |
| Extreme Load Limit | 300 % FS |
| Safe Load Limit | 150 % FS |
| Max Excitation Voltage | 18 V (DC) |
| Recommended Excitation Voltage | 5 V to 12 V (DC) |
| Zero Output (%FS) | ± 1.0 |
| Insulation Resistance | ≥ 5000 (50 V DC) |
| Output Sensitivity | 2.0 ± 0.02 mV/V |
| Sensitivity Drift | (% FS / 30 min) |
| Max Verification Divisions | 2000 |
| Comprehensive Error | ± 0.030 |
| Min Verification Interval | Emax / 5000 |
| Temperature Influence on Zero Output | (% FS / 50 °F (10 °C)) |
| Temperature Influence on Output Sensitivity | (% FS / 50 °F (10 °C)) |
| Operating Temperature Range | 14 °F to 104 °F (-10 °C to 40 °C) |
| Permissible Temperature Range | -31 °F to 158 °F (-35 °C to 70 °C) |
| Amount Load
| 11.02 lb (5 kg), 22.05 lb (10 kg), 44.09 lb (20 kg), 66.14 lb (30 kg), 110.23 lb (50 kg), 220.46 lb (100 kg), 440.92 lb (200 kg), 551.16 lb (250 kg), 661.39 lb (300 kg), 771.62 lb (350 kg), 1102.31 lb (500 kg) |
