Features
- Water supply metering
- No mechanical wear
- Excellent reliability
- Stability and consistency
- Diagnose battery abnormality
Technical Specifications
| Medium Temperature | Cold water |
| Counter Instructions | Digital |
| Medium Pressure | General water meter |
| Structure | Enclosure or top cover or flow sensor or digital display |
| Environmental Class | 0 |
| Thread | Bsp |
| Tamper Record | Yes |
| Power Supply | Lithium battery DC 3.6 V |
| Range Ratio | U0do U5d3 U3d at |
| Level Measurement | B |
| Principle | Speed of water meter |
| Work Environment | Dry water meter |
| Smart System | AMR or ami |
| Permanent Flow Rate | 88 ft³ per h, 141 ft³ per h (2.5 m³ per h, 4.0 m³ per h) |
| Start Flow Rate | 0.8 gal per h (3 L per h) |
| Ratio | 100, 160, 250, 315, 400, 500 |
| Accuracy | Class 2 |
| Pressure | 1.6 MPa |
| Pressure Loss | △p25 |
| Temperature | T30, T50, default T30 |
| Data Storage | 1 year of daily data storage, 24 months of historical data, (data storage mode can be customized according to customer requirements) |
| Power Outage Protection | After a power outage, the accumulated flow rate recorded before the outage and the corresponding time can be saved, and the power supply will be restored automatically after the restoration of power metering function. |
| Communication Interface | Infrared, M-BUS, RS485, NB-IoT, LoRaWAN 433 MHz, 866 MHz, 868 MHz, 915 MHz, 923 MHz, W-Mbus 433 MHz, 868 MHz, TTL, pulse (optional) |
| Power Supply | Lithium, DC 3.6 V |
| Protection Level | IP68 |
| Electromagnetic Class | E2 |
| Installation | Horizontal or vertical |
| Dimension | 8.07 in x 4.17 in x 3.3 in (205 mm x 106 mm x 84 mm) |
