| Initial Blind Zone |
No Blind Zone |
| SNR |
>10dB |
| Fiber Type |
G.652 |
| Connector |
APC (Interchangeable FC, SC, ST) |
| Fiber Type |
G.652 |
| Wavelength |
1550nm ±20nm |
| Max Dynamic Range |
30dB to 32dB to 36dB to 33dB to 35dB to 37dB |
| Event Blind Zone |
3.28 ft (1m) |
| ATT Blind Zone |
19.68 ft (6m) |
| Pulse Width |
3ns to 5ns to 10ns to 50ns to 80ns to 160ns to 320ns to 500ns |
| Ranging Accuracy |
± (2.5 ft (0.75 m) + Sample interval × 0.005% × Test distance) |
| Loss Accuracy |
±0.05 dB/dB |
| Sample Points |
16 k to 128 k |
| Sample Resolution |
0.05 m (5cm) to 16 m (1600cm) |
| Reflection Accuracy |
±3 dB |
| File Format |
SOR Standard File Format |
| Loss Analysis |
4-point method to 5-point method |
| Laser Safety Level |
Class II |
| Refresh Rate |
3Hz (Typ.) |
| Data Storage |
Internal storage: <3000 curves; External storage: 4GB |
| Connector |
FC/UPC (Interchangeable SC, ST) |
| Data Interface |
USB, Mini-USB, 10 M to 100 M Ethernet Port |
| Wavelength range |
800 nm to 1700 nm |
| Connector |
Universal FC/SC/ST |
| Test scope |
-50 dBm to +26 dBm |
| Uncertainty |
±5% |
| Calibration wavelength |
850 nm to 1300 nm to 1310 nm to 1490 nm to 1550 nm to 1625 nm to 1650 nm |
| Wavelength |
Consistent with OTDR output wavelength |
| Output power |
≥-5dBm |
| Stability |
CW, ±0.5 dB/15 min (Tester after 15 minutes of boot-up preheating) |
| Connector |
FC/UPC (Interchangeable SC, ST) |
| Wavelength |
650 nm ±20 nm |
| Output power |
≥10 mW |
| Mode |
CW to 1Hz to 2Hz |
| Connector |
FC/UPC (Interchangeable SC, ST) |
| Display |
5.6 in color LCD + touch screen |
| Power supply |
AC/DC adapter: Input 100V to 240V, 50 to 60Hz, 0.6A, Output: 12V to 19V, 1.5A, Lithium battery: 7.4V, 5000mAh |
| Relative Humidity |
0 % to 95 %, non-condensing |
| Operating Temperature |
-10 °C to +50 °C (14 °F to 122 °F) |
| Storage Temperature |
-40 °C to +70 °C (-40 °F to 158 °F) |
| Weight |
< (1.5 kg) 3.3 lbs |
| Dimension |
8.94 in × 6.3 in × 2.76 in (22.7 cm × 16 cm × 7 cm) |
