Technical Specifications
| Mounting Type | Complete machine |
| Application | RFID tag read and write |
| Type | UHF, Passive |
| Series | RFID IoT |
| Features | Protocol extension |
| Antenna | 4CH TNC |
| Protocol | ISO 18000-6C/6B, EPC C1G2, GB/T29768-2013 |
| Read Range | >10 m |
| Power Supply | DC 5 V to 12 V/4 A |
| Communication | RJ45, RS232, RS485, WiFi, 4G, BT |
| Chip | Impinj R2000 optional |
| Output Power | 33 dBm (1 dBm) Adjustable |
| Developing | C#, JAVA, Android |
| Frequency | 840 Mhz to 960 Mhz |
| Frequency Band (Optional) | ETSI: 865 MHz to 868 MHz; JP: 916.8 MHz to 920.4 MHz; TW: 922.25 MHz to 927.75 MHz ID: 923.125 MHz to 925.125 MHz; RUS: 866.6 MHz to 867.4 MHz; TEST: 802.75 MHz to 998.75 MHz JP_LBT: 916.8 MHz to 920.8 MHz |
| Modulation Mode | DSB-ASK, PR-ASK |
| Reading Speed | >600 pcs/s |
| Distance | About 49.21 ft (15 m) (built in antenna) |
| Function | Read & write function, Multiple label identification Label data filtering, RSSI sensing signal strength |
| System Support | Android |
| Hardware | 1 GB SRAM, 8 GB ROM |
| Display Port | HDMI 1080P |
| RF Port | 1 or 2 or 4 or 8 CH TNC, (16 CH SMA) |
| Material | Aluminum |
| Installation Method | Fixed by screw holes |
| Working Temperature | -4 °F to 158 °F (-20 °C to 70 °C) |
| Working Humidity | 10% RH to 90% RH |
| Size | 7.67 in × 6.06 in × 1.06 in (19.5 cm × 15.4 cm × 2.7 cm) |
