| Master Control |
Qualcomm 9531 master control chip, 128MB memory, 16M Flash |
| Power Supply |
DC12V |
| LoRa Frequency |
CN470-510 / EU863-870 / US902-928 / AS923 / AU915-928 / KR920-923 (Optional) |
| LoRa Communication Rate |
292bps to 5.4kbps, support spread factor SF7-SF12 |
| LoRa Tx Power |
17 dBm |
| Maximum Power |
20 dBm (at the antenna mouth) |
| LoRa Rx Sensitivity |
-141 dBm at SF12 |
| LoRa Antenna Gain |
2 dBi |
| LoRa Antenna Type |
Omni-direction |
| Channel |
8 uplinks, 1 downlink |
| LoRa Working Mode |
Half-duplex |
| Base Station |
Network |
| LTE Model |
Various frequency bands |
| WiFi |
2.4GHz, AP mode, Maximum power: 18 dBm |
| Debug Interface |
WiFi; LAN; serial port |
| Humidity |
5 % to 95 % |
| Power Consumption |
7W |
| Core |
Linux-4.14.88 |
| LoRa Protocol |
LoRaWAN V1.1 GWMP protocol, Class A / C |
| Packet Forwarding |
Supports UDP (GWMP) / MQTT (GWMP) / built-in NS / WSS (based on Basic Station’s CUPS and LNS protocols) |
| Built-in NS |
Up to 100 terminal connections, supporting MQTT / HTTP push decryption and data parsing |
| Modbus TCP |
Up to 5 client access, supports function code 03, reads temperature, humidity, voltage, and other data |
| User Interface |
WEB interface |
| Language and Interface |
Chinese/English with logo or neutral interface |
| 3G/4G Networking |
Supports Qualcomm universal dial-up QMI |
| IPv6 |
4G supports IPv6, LAN, and Wi-Fi provide IPv6 relay function |
| Local Time Synchronization |
Supports NTP client, different time zones can be set |
| WAN Port Protocols |
Static IP, DHCP client, and PPPoE. |
| Firmware Upgrade and Flashing |
Supports uploading firmware fresh in WEB and OTA remote upgrade |
| Wi-Fi Connectivity |
2.4GHz, 802.11b / g / n, WPA2 PSK encryption, support STA+AP mode |
| Firewall |
IP tables v1.8.2, support customized rule, SYN-flood protection |
| Network Load Balancing |
Optional switching between WAN and 4G, prioritizing WAN traffic with 4G as a backup |
| Gateway ID Generation |
Gateway ID generated based on WiFi MAC address |
| Local Log Management |
Support logs stored in TF card, clears when full |
| Fault Self-Diagnosis |
Supports system self-diagnosis, self-healing, and report results |
| Remote Management |
Supports remote firmware upgrades, restarts, and maintenance |
| LoRaWAN Protocol |
Supports standard LoRaWAN protocols V1.0.X (V1.0.2, 1.0.3, 1.0.4), V1.1 |
| Device Types |
Supports device types Class A and Class C |
| Uplinks and Downlinks |
8 uplink channels, 1 downlink channel |
| Packet Forwarding |
Supports UDP packet forwarding protocol, Basics Station CUPS, and LNS protocol |
| Server Switching |
Can switch between embedded NS or external NS server as needed |
| Data Transmission |
Embedded NS MQTT protocol supports data transmission even when disconnected |
| Wi-Fi Connection |
Supports WiFi connection to the gateway for monitoring and configuration |
| Firewall Protection |
Supports firewall protection, SYN-flood defense, and DNS rebinding protection |
| Remote Management |
Supports remote OTA upgrade, self-diagnosis, and repair |
| Log Storage |
Support for TF card log storage |
| RJ45 Ports |
Two external RJ45 ports, one for WAN and one for LAN |
| IPv6 Support |
Supports IPv6, provides public network IP addresses for LAN and Wi-Fi |
| Intelligent Switching |
Supports automatic switching between WAN and 4G, prioritizing WAN |
| LTE Coverage |
Supports LTE with three module options for China, Europe, and the US, ensuring full network coverage in China |
| Temperature |
14 °F to 122 °F (-10 °C to 50 °C) |
| Dimension |
7.09 in x 4.53 in x 1.18 in (18 cm x 11.5 cm x 3 cm) |
