Technical Specifications
| Computing | MT7628, DDR2 RAM 128 MB |
| Wi-Fi Feature | Frequency: 2.4 GHz (802.11b / g / n)
RX Sensitivity: -95 dBm (Min) TX Power: 20 dBm (Max) Operation Channels: 2.4 GHz: 1-13 SX1302 Mini PCIe card 8 Channels |
| LoRa Feature | RX Sensitivity: -139 dBm (Min)
TX Power: 27 dBm (Max) Frequency: EU433 / CN470 / EU868 / US915 / AS923 / AU915 / IN865 / KR920 |
| Cellular Support | Supports Quectel EG95-E/EG95-NA (IoT / M2M – optimized LTE Cat 4 Module) |
| EG95-E for EMEA Region | |
| LTE FDD: B1 / B3 / B7 / B20 / B28A | |
| WCDMA: B1 / B8 | |
| EG95-NA for North America Region | |
| LTE FDD: B4 / B5 / B12 / B13 | |
| WCDMA: B2 / B4 / B5 | |
| GSM / EDGE: B3 / B8 | |
| Optional supports other PCIe LTE module for Global Region | |
| Power Supply | DC 12 V – 1 A |
| PoE (IEEE 802.3 af): 36-57 VDC | |
| Computing | MT7628, DDR2 RAM 128 MB |
| Power Consumption | 12 W (typical) |
| ETH | RJ45 (10/100 M) |
| Console | Type-C USB |
| Antenna | LoRa: RP-SMA female connector |
| LTE: Internal antenna | |
| Wi-Fi: Internal antenna | |
| LEDs | POWER LED |
| Breathing LED (Top side) | |
| ETH LED (On ETH connector) | |
| LoRa LED | |
| WLAN LED | |
| LTE LED | |
| Ingress Protection | IP30 |
| Enclosure Material | Plastic |
| Installation Method | Wall mounting |
| Operating Temperature | 14 °F to 149 °F (-10 °C to 65 °C) |
| Dimension | 6.54 in x 5.00 in x 1.42 in (16.6 cm x 12.7 cm x 3.6 cm) |
| Weight | 10.58 oz (300 g) |
