Features
- 80GHz FMCW technology
- False echo suppression option
- Narrow beam, small blind zone and accurate measurement
- Unaffected by temperature fluctuations
- Resistant to dirt and buildup
- Measurement under vacuum and high pressure
- Small size, easy to use, less maintenance
Technical Specifications
| Grade | Industrial |
| Measuring Range | 0 ft to 98.4 ft (0 m to 30 m) |
| Frequency Range | 76 GHz to 81 GHz |
| Bandwidth | Instant 4 GHz |
| Accuracy | ±0.039 in (±1 mm) |
| Signal Output | 4-20 mA/HART |
| Digital Output | RS485/MODBUS |
| Connection | Bluetooth/NB-IoT/4G |
| Operating Voltage | DC 24±6V (2-wire) AC 220V (4-wire) |
| Antenna | Aluminum Alloy/Stainless Steel+PTFE horn lens antenna |
| Material | Aluminum Alloy/Stainless Steel + PTFE |
| Process Connection | Thread G1½; Flange DN50 |
| Medium Temperature | -40 to +248 °F (-40°C to +120°C) |
| Process Pressure | (-14.5 psi to 14.5 psi) (-0.1 MPa to 0.1 MPa) |
| Protection Grade | IP67 |
| Explosion-proof Grade | Ex ia IIB T4 Ga |
| Customized Support | OEM, ODM, OBM |
