Technical Specifications
| CPU | ARM Cortex-A7, 528 MHz |
| Memory | 128 MB DDR3 RAM, 128 MB Flash |
| Extendable Storage | 1 × Micro SD Slot |
| Antenna Connector | 2 × 50 Ω SMA Connectors |
| SIM Slots | 2 (Mini SIM-2FF) |
| WiFi Standards | IEEE 802.11 b/g/n, 2.4 GHz |
| WiFi Modes | AP or Client mode |
| Serial Interface | 1 × RS232 |
| Connector | 3.5 mm Terminal Block |
| Baud Rate | 300 bps to 230,400 bps |
| Power Supply | DC 9 to 48V input |
| Power Consumption | <5W |
| Dimensions | 5.35 × 3.86 × 1.46 in (13.6 × 9.8 × 3.7 cm) |
| Operating Temperature | -40°F to 158°F (-40°C to 70°C) |
| Storage Temperature | -40°F to 185°F (-40°C to 85°C) |
| Humidity | 5% to 95% non-condensing |
| Ethernet Ports | 2 × 10/100 Mbps |
| Installation | Wall or DIN rail mount |
