Features
- Seamless Conversion Between RS485 and Ethernet.
- Supports Modbus RTU/TCP Protocol for Flexible Connectivity.
- Industrial-Grade Design for Robust Performance.
Technical Specifications
| Interface Form | RJ45 |
| Speed | 10/100 Mbps |
| Number of Network Ports | 1 |
| Number of Serial Ports | 1 RS485 |
| Baud Rate | 1200 to 115200 bps |
| Power Supply Specification | 9 to 27 VDC |
| Working Environment | -40°F to 185°F, 5 to 95% RH (No Condensation) |
| Over-Voltage Protection | Power Supply: 30V / RS485: 5V / 100 mA |
| Overcurrent Protection | Power Supply: 500 mA / 200 mA / RS485: 5V / 100 mA |
| Size | 2.78 × 2.50 × 0.98 in (± 0.004 in, Excluding Terminals) |
| Material | Industrial-Grade Metal |
| Network Protocols Supported | Modbus RTU/TCP |
| Temperature Resistance | -40°F to 185°F (-40°C to 85°C) |
| Humidity Resistance | 5% to 95% RH |
| Power Consumption | Low Power consumption design |
