Features
- Industrial grade ARM 9 processor, 300MHz frequency.
- 128MB DDR3 SDRAM, 128M flash.
- Support 2 wire high-speed 10 or 100 M independent network interface.
- Support 2 or 4 wire RS 485 serial communication interface.
- Built-in real-time clock (RTC), temperature sensor, and independent hardware encryption circuit to protect user IP.
- Built-rich communication protocol library to support the electricity IEC60870-101 to 103 to 104 protocol, ProfiNET, EtherNet, BACnet, SNPx, Modbus TCP to IP, MQTT, OPC-IE, and other communication protocols.
- Built-in WEB server, support for remote development, configuration, commissioning, and maintenance.
- Achieve communication management, data gateway, data forwarding, protocol conversion, pre-processing, and other functions.
- CAN interface bidirectional optical isolation CAN2.0 interface standard.
- Support all the way debug serial port, as well as WIFI wireless LAN to GPRS to 3G to 4G remote communications and other extensions.
- Expandable 4 G to 128 G TF memory card.
- Rugged metal shell and internal circuit “three defenses” treatment, especially for the harsh environment on site.
Technical Specifications
| Chipset | ARM |
| Application | Data collector, data concentrator |
| Uplink Protocol | ProfiNET, EtherNet, BACnet, SNPx, etc |
| Downlink Protocol | Modbus RTU, Modbus TCP, Profibus DP |
| System Connection Method | RJ45, 4G, 3G, 2G, WIFI, etc. |
| Other Function | Expandable 4 G to 128 G TF memory card |
| Type | Modbus RTU gateway |
| Power Supply | AC (9 V to 48 V) |
| Power Consumption | <3 VA |
| Installation Method | DIN rail or Wall hanging installation |
