Features
- Supports the standard LoRaWAN protocol with global frequency band options
- Utilizes Semtech SX130X chips
- 8 Data Channels and 1 control channel, with full-duplex/half-duplex options
- Supports Winext IoT-vision, with built-in Net Serve options
- Compatible with network servers such as Tencent Cloud, LinkWAN, TTN, Chirpstack, Amazon, etc.
- Supports IPv6 and Modbus TCP protocol
- Transmission range up to 15 kilometers
- IP67 Protection Rating
- Supports standard PoE (Power over Ethernet) power supply
- Supports for Class A/B/C
- Integrated WiFi/GPS/LTE/LoRa Antenna
- Certified with CE and FCC
Technical Specifications
| CPU | Industrial Grade CPU operating at 400MHz |
| Memory | 64M DDR2 RAM, 16M SPI FLASH |
| System | Linux-3.18.27 (32-bit system, 128kB L2 cache) |
| LoRa Data Rate | 292bps to 5.4Kbps |
| Ethernet Communication Rate | 100Mbps |
| LTE Communication Rate | 50Mbps |
| Working Frequency | CN470510MHz, EU863870MHz, US902928MHz, AS920925MHz, AU915928MHz, KR920923MHz, RU864~870MHz, IN865-867MHz |
| Max Transmission Power | 26dbm |
| Rx Sensitivity | -142dBm@SF12 (half-duplex) or -138dBm@SF12 (full-duplex) |
| Channels | 8 Data Channels, 1 Control Channel |
| Communication Interface | 1LAN, 1WAN, 1WIFI, 1LTE module |
| Input | POE power supply with 48V input (24 to 8V) |
| Power Consumption | 7W |
| Installation | Wall-mounted or Pole-mounted |
| Certificate | CE or FCC |
| Thunder Protection | Optional |
| Ingress Protection | IP67 |
| Working Temperature | -40℉ to 176℉ (-40℃ to 80℃) |
| Dimension | 11.33 in x 8.46 in x 2.32 in (28.8 cm x 21.5 cm x 5.9 cm) |
