| Ethernet Port Interface |
1 WAN port and 6 LAN ports |
| Industrial Serial Port |
3 RS485 |
| WIFI |
1 road |
| Optical Fiber |
SC port or FC port |
| Function |
For smart light pole networking |
| Battery |
No battery |
| Input Voltage |
DC 24V |
| Wireless Protocol |
4G LTE |
| Optical Fiber Cascade Interface |
Gigabit Optical Port, SC port or FC port |
| Optical Fiber Mode |
Single-mode single-fiber or single-mode dual-fiber |
| Communication Distance |
20km, optional 100km |
| Connection Mode |
Cascade connection, ring connection |
| Industrial Serial Port Form |
RJ45T industry terminal |
| Serial Port Type |
RS-485 |
| Serial Port Parameters |
1200 to 115200bps, 8 data bits, No parity/odd/even parity |
| Ethernet Port Interface (WAN) |
1 WAN port, 10/100M/1000M adaptive, RJ45 interface |
| Ethernet Port Interface (LAN) |
6 LAN ports, IEEE 802.3, IEEE 802.3u, 10/100M/1000M |
| WIFI Standards |
IEEE802.11b/g/n, max bandwidth 54Mbps (b/g), 300Mbps (n) |
| WIFI Security Encryption |
WEP, WPA, WPA2 |
| WIFI Modes |
STA mode, AP mode, Repeater mode |
| Indicators |
3 (Driver, operating status, network) |
| Antenna Interface |
1 SMA interface, WIFI antenna |
| USB Interface |
1 USB interface |
| Debug Interface |
1 Micro USB interface |
| CPU |
NXP LS1012A Cortex-A53, Edge computing, 1G main frequency |
| DDR |
512 MB, expandable to 1 GB |
| FLASH |
8 GB eMMC, expandable to 1 GB |
| Button |
1 Reset button |
| Link Detection |
Supports multi-level link detection mechanisms |
| Built-in Watchdog |
Equipment self-check technology, automatic self-recovery |
