| Application |
INDUSTRIAL |
| Communication Network |
Start topology |
| LoRaWAN Protocol |
Class A, Class B, Class C |
| Working Frequency |
EU433, CN470-510, CN779-787 |
| Communication Distance |
3.728 mi (6 km) |
| Location |
GPS, Beidou |
| Wireless Management |
WIFI management and upgrade |
| Local Storage |
32G TF card |
| Communication Bandwidth |
125 kHz, 250 kHz, 500 kHz |
| Communication Network |
Star topology |
| LoRaWAN Protocol |
Class A, Class B, Class C |
| Working Frequency |
EU433, CN470-510, CN779-787, EU863-870, US902-928, AU915-928, AS923, KR920-923 |
| Communication Distance (Outdoor) |
6 km |
| Max TX Power |
25 ± 2 dBm |
| RX Sensitivity |
Max -140 dBm @ LoRa; -70 dBm @ WiFi |
| Communication Bandwidth |
125 kHz, 250 kHz, 500 kHz |
| Channels |
8 upstream channels, 1 downstream channel |
| Data Loss |
No data loss and no relay wireless communication |
| Speed |
Link Adaptive Speed |
| Work Mode |
Support different frequency and same frequency |
| Location |
GPS, Beidou |
| Report To Server |
3G/4G, Wired network |
| Wireless Management |
WiFi management and upgrade |
| Local Storage |
32 GB TF card |
| Antenna Interface |
I-pex to N type, external |
|
LoRa antenna: N-type female, LoRa fiberglass antenna, 2 dBi gain |
|
4G antenna: N-type female, 4G fiberglass antenna, 3 dBi gain |
|
WiFi antenna: N-type female, 2.4G fiberglass antenna, 3 dBi gain |
|
GPS antenna: N-type female, GPS fiberglass antenna, 4 dBi gain |
| Power |
Power options: AC220, POE, Solar power |
|
POE port supports auto 10/100 Base-T |
|
POE standard: IEEE802.3af/IEEE802.3at |
| Consumption |
Standby: Average current 140mA @ 12V |
|
Communication: |
|
– Transmit current: 550mA @ 12V |
|
– Receive current: 420mA @ 12V |
| Working Temperature Range |
-40°F to 185°F (-40°C to +85°C) |
| Storing Temperature Range |
-40°F to 257°F (-40°C to +125°C) |
