| Chipset |
ARM 9 |
|
| Application |
Collect data, used for wiring modbus gateway |
|
| Material |
Metal |
|
| Accessories |
DC power supply, circuit breaker, wire, DIN-rail, etc |
|
| Rated Voltage |
6V to 24V DC, 12 VDC recommended |
|
| Power Consumption |
<3 VA |
|
| LAN |
1 × 10/100M RJ45 interface |
|
| Serial Port |
2 × RS485 port + 1 × RS232 |
|
| Communication Master Station Protocols |
Around 50/pc |
|
| Transmission Mode |
Full or Half duplex |
|
| Dual Machine Switching Time |
<5 s |
|
| MTBF |
>50000 h |
|
| Status Indication |
Panel LED, reflecting the serial port data transmission and reception status |
|
| Standard Protocol |
IEC60870-5-101/103/104, MODBUS, CDT |
|
| Special Protocol |
DNP3.0 and other over 30 protocols, can be developed according to onsite needs |
|
| Relative Humidity |
5% to 95%, no condition |
|
| Ambient Temperature |
-13 °F to +158 °F (-25 °C to +70 °C) |
|
| Storage Temperature |
-22 °F to +167 °F (-30 °C to +75 °C) |
|
| Mounting type |
Wall mounted |
|
| Size |
4.72 in × 2.83 in × 1.22 in (12 cm × 7.2 cm × 3.1 cm) |
|
| Weight |
3.3 lb (1.5 kg) |
|
| Working Power |
Rated voltage |
6-24 VDC, 12 VDC recommended |
|
Power consumption |
<3VA |
| Capacity Index |
LAN |
1* 10/100M RJ45 interface |
|
Serial port |
2 * RS485 port +1 * RS232 |
|
Communication master station protocols |
Around 50/pc |
|
Transmission mode |
Full or half duplex |
| Performance Index |
Dual machine switching time |
<5s |
|
MTBF |
>50000h |
|
Status indication |
Panel LED, reflecting the serial port data transmission and reception status |
| Protocol |
Standard protocol |
IEC60870-5-101/103/104, MODBUS, CDT. |
|
Special protocol |
DNP3.0 and other over 30 protocols, can be developed according to onsite needs |
| EMC |
Fast pulse group immunity |
IEC61000-4-5, level 3 |
|
Surge immunity |
IEC61000-4-2, level 3 |
|
Electrostatic immunity |
IEC61000-4-4, level 3 |
