Features
- Support intellectual mode
- Communication state automatically when powered
- Provide management software for remote
- Support several work modes
- Convenient configuration and maintenance interface
- High-performance
- Support hardware and software WDT
- Support auto recovery mechanism
Technical Specifications
| CPU | Industrial 32 bit |
| FLASH | 512 KB |
| SRAM | 256 KB |
| Serial | 1 RS232 port and 1 RS 485 (or RS 422) port |
| Power Range | DC 5 V to 36 V |
| Communication | 15 mA to 20 mA and 12 V DC |
| Deep Sleep | 35 μA to 40 μA and 12 V DC |
| Operating Temperature | -31 °F to 167 °F (-35 °C to +75 °C) |
| Dimensions | 3.58 in x 2.3 in x 0.87 in (91 mm x 58.5 mm x 22 mm) |
| Weight | 0.46 lb (210 g) |
