Features
- OpenWrt based Linux OS programmable environment for C/C++, Python, LUA via SDK(Option)
- 5G NR Sub-6 bands with SA and NSA dual modes, supports up to DL: 3.4Gbps, UL: 250Mbps, ideal for IoT, M2M and eMBB applications
- Global 5G and LTE-A coverage, back support 3G
- WWAN and WAN failover
- 4G and 5G WIFI (802.11b/n/g/ac, Option)
- 5 x Gigabit Ethernet port
- 1-RS232, 1-RS485, 2-DI, 3-ADC, 3-DO(Relay), 3-Power Output
- Up to 32G (via Micro SD card) local data storage and backup
- MQTT, Modbus RTU/TCP, TCP/UDP, HTTP, SNMP protocols 10. Multiple VPN protocols, IPsec, L2TP, PPTP, GRE and OpenVPN
Technical Specifications
| Programmable | Python, C/C++ |
| Application | AGV, Robot, smart factory, industrial automation |
| Ethernet Ports | 5 x 10/100/1000 Mbps |
| Digital Input | 2-DI |
| Relay Output | 3-Relay |
| Analog Input | 3-ADC (4 mA to 20 mA or 0 V to 5 V) |
| Power Output | 2-DC Power output |
| Wireless | 5G NR SA/NSA, 4G LTE, WIFI*, GNSS* |
| External Storage | 1x Micro SD interface, up to 32G |
| Network Protocols | SNMP, RIPv1/v2, OSPF, BGP, DNS, DDNS, HTTP, Telnet, SSH |
| VPN | IPsec/PPTP/L2TP/GRE/OpenVPN |
