Features
- Supports Multiple Wireless Connectivity Standards
- Designed for Low Power Consumption
- Flexible Communication Protocol Support
- Rugged and Industrial-Grade Construction
- Global Coverage for Seamless Connectivity
- Compact and Easy to Integrate
- Wide Voltage Range for Flexibility
- Secure and Reliable Data Transmission
Technical Specifications
| Microcontroller | ARM® Cortex®-M33 |
| Performance | 243 EEMBC CoreMark score (running from flash memory) |
| Debug & Trace | DWT, ETM, ITM, SWD, Trace Port |
| Memory | 1 MB Flash, 256 kB Low Leakage RAM |
| Security | ARM® TrustZone®, ARM® CryptoCell 310 |
| SPI Interfaces | 4x SPI Master/Slave with EasyDMA |
| I2C Interfaces | 4x I2C-compatible Two-Wire Master/Slave with EasyDMA |
| UART Interfaces | 4x UART (CTS/RTS) with EasyDMA |
| I2S Interface | I2S with EasyDMA |
| Digital Microphone Interface | PDM with EasyDMA |
| PWM Units | 4x Pulse Width Modulator (PWM) with EasyDMA |
| ADC | 12-bit, 200 ksps, 8 configurable channels with gain |
| Timers & Counters | 2x 32-bit Timers with Counter Mode |
| Real-Time Counter (RTC) | 2x RTC |
| Peripheral Interconnect | Programmable Peripheral Interconnect (PPI) |
| General Purpose I/O | 32 GPIO Pins |
| Power Supply | 3.0 to 5.5 V Single Supply |
| Size | 0.39 in × 0.63 in (10 mm x 16 mm) |
